MDY-type hydraulic cotton baler technical specifications and main parameters



MDY-type hydraulic cotton baler technical specifications and main parameters Nominal force: 4000kN, strong force: 5000kN Package size: 1400mm×530mm×(700~800)mm Package weight (lint…

MDY-type hydraulic cotton baler technical specifications and main parameters

Nominal force: 4000kN, strong force: 5000kN
Package size: 1400mm×530mm×(700~800)mm
Package weight (lint): 227kg±l0kg
Compression height: 485~500mm
Output (lint): 4.5t/(unit h)
Installed capacity (including auxiliary machines): 82kW
Overall machine weight: about 58t
Main machine height: about 8700mm
Output: MDY —400 type 20 packs/(Taiwan h)
MDY—400A type 25~30 packs/(Taiwan h)
Equipped with power: MDY—400 type 82.4kW
MDY—400A type 97.4kW
Machine weight: MDY-400 type 55t
MDY-400A type 56t
